Vertex Plan Radiator
Stelrad radiator product for heating applications.
Features:
- Vertical radiator
- Decorative
- Flat front
- Available in colour
Official documents are available in the downloads section.
For availability, project compatibility and correct technical selection, contact Thomas Moudouros Ltd.
Technical table
| Item | Detail |
|---|---|
| Product: | decorative vertical radiator with a centre connection and a flat front |
| Finishing: | decorative flat front and side panels |
| Also supplied: | wall brackets, ETA safety screws and plugs, screws, plugs, air vent, blind plugs and installation instructions |
| Connections: | 4 x ½” female connection (centre connection included) |
| Lugs: | no lugs |
| Packaging: | Every radiator is sturdily packaged in high-quality cardboard and wrapped in plastic. The radiator's characteristics are shown on the label: type – height – length. |
| Warranty: | 10 years, as long as the installation instructions have been followed and Stelrad's warranty conditions have been met. |
| Paint process: | All radiators are degreased, phosphated, cataphoretically primed and powder-coated in Stelrad white 9016 as standard. |
| Colours: | Stelrad white 9016 + 35 different Stelrad colours and about 200 RAL-colours are possible |
| Max. operating pressure: | 10 bar (tested to 13 bar) |
| Max. operating temperature: | 110 °C |
| Conformity: | in accordance with EN442 |
| Quality assurance: | NF |
| Types: | 11 | 20 | 21 | 22 |
| Heights: | 1.600 | 1.800 | 2.000 | 2.200 mm |
| Lengths: | 300 | 400 | 500 | 600 | 700 mm |
| Depths: | 49 | 79 | 79 | 102 mm |
Technical documents (8)
For an accurate quote, send us
- Where the product will be used
- Quantity or dimensions where available
- Photos, drawings or material list if available
- Whether you need store collection or delivery
